Harley-Davidson Fat Boy vs KTNS RA2 Comparison

Engine & Performance

Displacement	1868 cc	250 cc
Fuel Tank Capacity (litres)	18.9 L	13 L
Cooling System	Air Cooled	Air Cooled
Bore X Stroke	102 mm x 114.3 mm	--
Valves Per Cylinder	4	--
Engine Type	2 Cylinder, V-Twin, Air Cooled, 4-Valve, Milwaukee-Eight	Single Cylinder, 4-Stroke, Air Cooled
No. Of Cylinder	2	1
Compression Ratio	10.5:1	--
Drive Type	Belt Drive	Chain Drive
Exhaust Pipes	Dual Exhaust	--
Maximum Torque	155 Nm	18 Nm
RPM at Maximum Torque	3000 rpm	6000 rpm
Maximum Power	--	19 hp
Top Speed	--	115 kmph
No. Of Strokes	--	4-Stroke
RPM at Maximum Power	--	8000 rpm

View All

Dimension

Category	Cruiser	Cruiser
Dry Weight	304 kg	--
Ground Clearance	130 mm	145 mm
Seat Height	675 mm	715 mm
Length	2370 mm	2061 mm
Seating Capacity	--	2
Height	--	1105 mm
Wheel Base	--	1380 mm
Kerb Weight	--	149 kg
Width	--	835 mm

View All

Fuel & Ignition

Start Option	Electric	Electric
Fuel Type	Petrol	Petrol
Fuel Supply System	EFI	--

Gear & Transmission

Transmission Type	Manual	Manual
Gear Box	6-Speed	6-Speed

Wheels & Tyres

Front Tyre	160/60 R18	110/80 R18
Rear Tyre	240/40 R18	140/90 R15
Tyre Type	Radial, Tubeless	Tubeless
Rear Wheel Size	R18	R15
Front Wheel Size	R18	R18

Electrical

Battery Voltage

12 V

12 V

Chassis & Suspension

Front Suspension	--	Upright
Rear Suspension	--	Pneumaticdual

Safety & Security

ABS	Yes	Yes
Pass Switch	Yes	Yes
Back Rest	No	--
Launch Control	No	No
Side Reflectors	Yes	Yes
Engine Check Warning	Yes	--
Riding Modes	Street, Road Street, Road	--
Shutter Lock	No	No
Engine Immobilizer	--	No
Anti-Theft Alarm	--	No
Leg Guards	--	No
Central Locking	--	No
Wheel Lock Front/back	--	No
Stability Control	--	No
Traction Control	--	No

View All

Console

Odometer	Digital Digital	Digital Digital
Speedometer	Analog Analog	Digital Digital
Display Screen	Yes	Yes
Navigator	No	No
Tripmeter	Yes	Yes
Fuel Gauge	--	Digital Digital
Tachometer	--	Yes

View All

Chassis & Suspension

Seat Type	Dual Stepped Dual Stepped	Double Seat Double Seat
Body Frame Material	Steel Steel	Steel Steel
Chrome Garnish	Yes	--
Side Wings	No	No
Body Frame Type	--	Turbular Turbular

Electrical

Indicator Light	Yes	Yes
Adjustable Headlights	Yes	Yes
Tail Lamp	LED LED	LED LED
Head Lamp	LED LED	Bulb Bulb
Accessory Outlet	--	No

Brake

Front Brake	Disc Disc	Disc Disc
Rear Brake	Disc Disc	Disc Disc

Differentiating Features

Height Adjustable Seats	--	No
Cruise Control	--	No
